Function:Receiving signals from computer then fedding to receiving card/receiver/scan board.If you want to play DVDs,live show videos,you can choose our led video processor to get a better image.
Can put inside the PC by PCI slot, or put outside the PC by adding a 5V power supply.
One TS802 LED Sending card can max support 2048(width)*640(height) pixels (with U and D outputs).
One SD802D led control card with one network cable output can support 1600*400 or 2048*320 pixels.
Model 802 has the audio data transmission function. To apply TS802's audio function, a function board is needed.
Its dip switch can realize max four cards cascaded, to meet a larger resolution needs (eg.2048*1152,4096*640,4096*1152 etc.)
TS802 is full-color sender, can control real pixel, virtual pixel,full-color, double colorand single color display.
